LX Tap and Reamer Collets
Size Overview:
Series |
A
Max Tool Size |
D
Diameter |
L
OAL |
S
Collet Square |
LX1 |
0.375" |
0.626" |
1.01" |
0.393" |
LX2 |
0.6" |
1.000" |
? |
0.623" |
LX3 |
1"+? |
1.375" |
1.44" |
0.932" |
LX4 |
1.3"+? |
1.875" |
? |
1.250" |
LX5 |
1.9"+? |
2.625" |
? |
1.838" |
|
|
Square Drive LX Collets
(For Taps & Reamers with Driving Square)
Tap Size |
Tool
Shank |
Tool
Square |
1LX |
2LX |
3LX |
4LX |
5LX |
0 to #6 |
0.141 |
0.110 |
x |
|
|
|
|
5/32" |
0.160 |
0.125 |
x |
|
|
|
|
3/16" |
0.192 |
0.149 |
x |
|
|
|
|
7/32" |
0.223 |
0.167 |
x |
|
|
|
|
1/4" |
0.255 |
0.191 |
x |
x |
x |
x |
x |
1/8" Pipe |
0.312 |
0.234 |
x |
|
|
|
|
5/16" |
0.318 |
0.238 |
x |
x |
x |
x |
x |
7/16" |
0.323 |
0.242 |
x |
x |
x |
x |
x |
1/2" |
0.367 |
0.275 |
x |
x |
x |
x |
x |
3/8" |
0.381 |
0.286 |
x |
x |
x |
x |
x |
9/16" |
0.429 |
0.322 |
|
x |
x |
x |
x |
5/8" |
0.480 |
0.360 |
|
x |
x |
x |
x |
11/16" |
0.542 |
0.406 |
|
x |
x |
x |
x |
1/4" Pipe |
0.562 |
0.421 |
|
x |
|
|
|
3/4" |
0.590 |
0.442 |
|
x |
x |
x |
x |
1/2" Pipe |
0.687 |
0.515 |
|
|
x |
|
|
7/8" |
0.697 |
0.523 |
|
|
x |
x |
x |
3/8" Pipe |
0.700 |
0.531 |
|
|
x |
|
|
1" |
0.800 |
0.600 |
|
|
x |
x |
x |
1-1/8" |
0.896 |
0.672 |
|
|
x |
x |
x |
3/4" Pipe |
0.906 |
0.679 |
|
|
x |
x |
|
1-1/4" |
1.021 |
0.766 |
|
|
x |
x |
x |
1-3/8" |
1.108 |
0.831 |
|
|
|
x |
x |
1" Pipe |
1.125 |
0.843 |
|
|
|
x |
x |
1-1/2" |
1.233 |
0.925 |
|
|
|
x |
x |
1-5/8" |
1.305 |
0.979 |
|
|
|
x |
x |
1-1/4" Pipe |
1.312 |
0.984 |
|
|
|
x |
x |
1-3/4" |
1.430 |
1.072 |
|
|
|
|
x |
1-1/2" Pipe |
1.500 |
1.125 |
|
|
|
|
x |
1-7/8" |
1.519 |
1.139 |
|
|
|
|
x |
2" |
1.644 |
1.233 |
|
|
|
|
x |
2-1/8" |
1.769 |
1.327 |
|
|
|
|
x |
2" Pipe |
1.875 |
1.406 |
|
|
|
|
x |
2-1/4" |
1.894 |
1.421 |
|
|
|
|
x |
|
|
Tang Drive LX Collets
(For Reamers with Driving Tang)
Reamer Size |
Tool
Shank |
Tool
Tang |
1LX |
2LX |
3LX |
1/8" |
0.119 |
? |
x |
|
|
5/32" |
0.151 |
0.106 |
x |
|
|
3/16" |
0.181 |
0.106 |
x |
|
|
7/32" |
0.208 |
0.134 |
x |
|
|
1/4" |
0.245 |
0.134 |
x |
|
|
9/32" |
0.249 |
0.134 |
x |
|
|
5/16" |
0.281 |
0.174 |
x |
x |
|
11/32" |
0.281 |
0.174 |
x |
x |
|
3/8" |
0.312 |
0.174 |
x |
x |
|
13/32" |
0.312 |
0.174 |
x |
x |
|
7/16" |
0.375 |
0.215 |
|
x |
|
15/32" |
0.375 |
0.215 |
|
x |
|
1/2" |
0.437 |
0.255 |
|
x |
|
17/32" |
0.437 |
0.255 |
|
x |
|
9/16" |
0.437 |
0.255 |
|
x |
|
19/32" |
0.437 |
0.255 |
|
x |
|
5/8" |
0.562 |
0.317 |
|
x |
x |
21/32" |
0.562 |
0.317 |
|
x |
x |
11/16" |
0.562 |
0.317 |
|
x |
x |
23/32" |
0.562 |
0.317 |
|
x |
x |
3/4" |
0.625 |
0.387 |
|
|
x |
25/32" |
0.625 |
0.387 |
|
|
x |
13/16" |
0.625 |
0.387 |
|
|
x |
27/32" |
0.625 |
0.387 |
|
|
x |
7/8" |
0.750 |
0.457 |
|
|
x |
29/32" |
0.750 |
0.457 |
|
|
x |
15/16" |
0.750 |
0.457 |
|
|
x |
31/32" |
0.750 |
0.457 |
|
|
x |
|
|
